VKA 17-1BW (#19x108)

The hand-held pneumatic rock drill VKA17-1W is a light weight tool used for drilling holes for secondary breaking in blasting operations in quarries, construction works, railways etc.

Benefits of use

  • The hammer is designed to reduce vibrations, putting less stress on operator's hands.
  • Removal of the grit from the hole is ensured by a central duct wash.

Specifications

Weight Air consumption Impact energy Impact frequency Oper. air pressure
17,5 kg 2,8 m3min-1 30 J 37 Hz 0,4 – 0,7 MPa
Torque Number of hits / one turn of drill rod Length x Width Air supply hose Water supply hose
5 Nm 12 643 x 455 mm Ø 16-20 mm Ø 13 mm
Connecting thread Effective value of weighted acceleration Measured sound power level Guaranteed noise level LWA Bore Diameter
G 3/4'' Quick Coupling 8,6 m.s-2 110.7 dB 112 dB(A) 26 – 32 mm
Direction of rotation of the drill stem Bore rod shank Ordering code
Vlevo - Left – Влево #19x108 (3/4x4 ¼”) 9403-600
VKA 17-1BW (#19x108)
