VK35 CWS (#22x108)

Pneumatic hammer drill VK 35S is used to drill boreholes for blasting work in rocks of varying hardness, especially in mines, road and railway construction, civil construction, etc. The hammer can be used as a drilling unit for a suitable light feed device.

Benefits of use

  • Removal of the grit from the hole is ensured by a central duct wash.
  • Used hammer construction materials allow working in explosive environments.

Specifications

Weight Air consumption Impact frequency Oper. air pressure Torque
30 kg 5,2 m3min-1 31 Hz 0,4 – 0,7 MPa 21 Nm
Number of hits / one turn of drill rod Length x Width Air supply hose Water supply hose Connecting thread
12 644 x 260 mm Js25 mm Js13 mm G1“
Effective value of weighted acceleration Measured sound power level Guaranteed noise level LWA Bore Diameter Direction of rotation of the drill stem
24,5 m.s-2 114.3 dB 115 dB(A) 34 - 45 mm Vlevo - Left – Влево
Bore rod shank Ordering code
# 22x108 (7/8x4 ¼”) 9403-640
