BK 40-B (#28x160)

The breaking hammer is a versatile tool. It is designed for breaking up low to medium strength rock and material (concrete, bituminous roadways, masonry etc.). Its design and weight favors its use in downwards-horizontal or sloping direction.

Benefits of use

  • HIGH RATIO PERFORMANCE/WEIGHT ENABLE LOWER PHYSICAL WORK FOR THE OPERATORS
  • LONG LASTING RESISTANCE OF MATERIALS
  • SIMPLE CONSTRUCTION ENABLES EASY MAINTENANCE AND REPAIR WORKS
  • PISTON WITH AIR CUSHION
  • HIGH IMPACT ENERGY
  • HIGH SERVICE LIFE AND RELIABILITY
  • LARGE SELECTION OF TOOLS AND ACCESSORIES

Specifications

Weight Impact energy Impact frequency Air consumption Oper. air pressure
41 kg 105 J 16 Hz 1,9 m3min-1 0,4 – 0,7 MPa
Effective value of weighted acceleration Measured sound power level Guaranteed noise level LWA Length x Width Air supply hose
9,5 m.s-2 105,2 dB 106 dB 760 x 435 mm Js 16
Connecting thread Tool shank size Ordering code
G 3/4'' Quick Coupling #28x160 9461-270
BK 40-B  (#28x160)
